• Air conditioning, single-zone manual
• Coat hook, driver-side rear
• Cruise control
• Door trim, integral armrests and driver- and front passenger-side map pockets with padded cloth inserts
• Floor mats, rubberized-vinyl front and rear
• Mirror, inside rearview manual day/night
• Power outlets, 2 auxiliary, covered, 12-volt
• SLE decor (Deluxe Cloth)
• Steering column, Tilt-Wheel
• Steering wheel, leather-wrapped
• Theft-deterrent system, vehicle, PASSlock

• Alternator, 125 amps
• Battery, heavy-duty 590 cold-cranking amps, maintenance-free with rundown protection
• Brakes, 4-wheel antilock, front disc/rear drum
• Four wheel drive
• Front underbody shield (4WD models only)
• Pickup box, Fleetside, all-welded steel with double-wall construction and corrosion protection with 4 cargo tie-downs
• Steering, power, rack-and-pinion
• Suspension, rear semi-floating axle with 2-stage multi-leaf springs
• Transfer case, Insta-Trac, electronic shift with dash-mounted controls (Standard on 4WD models only)

• Daytime Running Lamps with automatic exterior lamp control
• Safety belts, 3-point, driver and right-front passenger, adjustable (center position lap belt with bench seat only)
• Safety belts, 3-point, rear, all seating positions
• Tire Pressure Monitor

TRAILERING EQUIPMENT

• includes (VR4) trailer hitch and (UY7) 7-wire harness

TIRE, SPARE P235/75R16 ALL-SEASON, BLACKWALL

• Included with (Z71) High-Stance Off-Road Suspension Package)

TRANSMISSION, 4-SPEED AUTOMATIC

• electronically controlled with overdrive (STD)

SEATS, FRONT BUCKET

• with (**J) SLE Deluxe Cloth
• includes integral outboard head restraint
• manual recliners
• center floor console with storage and armrest (STD)

AUDIO SYSTEM, AM/FM STEREO

• with CD/MP3 player
• seek-and-scan
• digital clock
• auto-tone control
• Radio Data System (RDS)
• speed-compensated volume
• 4 speakers on Regular Cab and 6 speakers on Extended and Crew Cab (STD)

SLE2 PREFERRED EQUIPMENT GROUP

• Includes Standard Equipment

SUSPENSION PACKAGE, HIGH STANCE OFF-ROAD

• includes (R03) 4-17" x 7" (43.2 cm x 17.8 cm) chrome clad wheels
• (QJP) P265/70R17 on-/offroad
• blackwall tires
• front torsion bars
• 28mm front stabilizer bar
• urethane jounce bumpers
• (B71) large wheel flares and (G80) automatic locking rear differential

ENGINE, 5.3L V8 SFI

• (300 hp [223.7 kW] @ 5200 rpm
• 320 lb-ft of torque [432.0 N-m] @ 4000 rpm)

AIR BAGS, HEAD CURTAIN SIDE-IMPACT, FRONT AND REAR OUTBOARD SEATING POSITIONS

• with Passenger Sensing System

• WHEEL FLARES FRONT AND REAR LARGE BODY-COLOR (Z71 ONLY)
• TRAILERING EQUIPMENT includes (VR4) trailer hitch and (UY7) 7-wire harness
• TIRES P265/70R17 ON-/OFF-ROAD BLACKWALL
• FIRE RED
• WHEELS 4-17" X 7" (43.2 CM X 17.8 CM) CHROME CLAD
• TIRE SPARE P235/75R16 ALL-SEASON BLACKWALL Included with (Z71) High-Stance Off-Road Suspension Package)
• REAR AXLE 4.10 RATIO
• TRANSMISSION 4-SPEED AUTOMATIC electronically controlled with overdrive (STD)
• SEATS FRONT BUCKET with (**J) SLE Deluxe Cloth includes integral outboard head restraint manual recliners center floor console with storage and armrest (STD)
• AUDIO SYSTEM AM/FM STEREO with CD/MP3 player seek-and-scan digital clock auto-tone control Radio Data System (RDS) speed-compensated volume 4 speakers on Regular Cab and 6 speakers on Extended and Crew Cab (STD)
• LICENSE PLATE BRACKET FRONT
• SLE2 PREFERRED EQUIPMENT GROUP Includes Standard Equipment
• SUSPENSION PACKAGE HIGH STANCE OFF-ROAD includes (R03) 4-17" x 7" (43.2 cm x 17.8 cm) chrome clad wheels (QJP) P265/70R17 on-/offroad blackwall tires front torsion bars 28mm front stabilizer bar urethane jounce bumpers (B71) large wheel flares and (G80) automatic locking rear differential
• GVWR 5500 LBS. (2495 KG)
• DIFFERENTIAL AUTOMATIC LOCKING REAR
• ENGINE 5.3L V8 SFI (300 hp [223.7 kW] @ 5200 rpm 320 lb-ft of torque [432.0 N-m] @ 4000 rpm)
• AIR BAGS HEAD CURTAIN SIDE-IMPACT FRONT AND REAR OUTBOARD SEATING POSITIONS with Passenger Sensing System
• EBONY SLE DELUXE CLOTH
• ALTERNATOR 145 AMPS
• Keyless Entry
• Power Door Locks
• Power Mirror(s)
• Power Windows
• Four Wheel Drive
• Tow Hooks
• Power Steering
• ABS
• Front Disc/Rear Drum Brakes
• Tires - Front All-Season
• Tires - Rear All-Season
• Temporary Spare Tire
• Fog Lamps
• Power Mirror(s)
• Privacy Glass
• Sliding Rear Window
• Intermittent Wipers
• Bed Liner
• AM/FM Stereo
• CD Player
• MP3 Capability
• Satellite Radio
• Requires Subscription
• Cloth Seats
• Bucket Seats
• Cloth Seats
• Floor Mats
• Leather Steering Wheel
• Adjustable Steering Wheel
• Immobilizer
• Cruise Control
• A/C
• Power Outlet
• Passenger Vanity Mirror
• Child Safety Locks
• Traction Control
• Stability Control
• Daytime Running Lights
• Driver Air Bag
• Passenger Air Bag
• Passenger Air Bag Sensor
• Telematics
• Requires Subscription
• Tire Pressure Monitor

• Mileage
• Fuel Economy Est-Combined (MPG): 16
• Fuel Economy Est-Combined (MPG): 17
• EPA Fuel Economy Est - City (MPG): 14
• EPA Fuel Economy Est - City (MPG): 16
• EPA Fuel Economy Est - Hwy (MPG): 19
• EPA Fuel Economy Est - Hwy (MPG): 21
• Electrical
• Cold Cranking Amps @ 0° F (Primary): 590
• Maximum Alternator Capacity (amps): 145
• Maximum Alternator Capacity (amps): 125
• Cooling System
• Total Cooling System Capacity (qts): - TBD -
• Weight Information
• Gross Axle Wt Rating - Front (lbs): 2850
• Gross Axle Wt Rating - Rear (lbs): 2896
• Curb Weight - Front (lbs): 2295
• Curb Weight - Rear (lbs): 1674
• Gross Vehicle Weight Rating Cap (lbs): 5500
• Gross Vehicle Weight Rating Cap (lbs): 5300
• Gross Combined Wt Rating (lbs): 10400
• Gross Combined Wt Rating (lbs): 9800
• Trailering
• Dead Weight Hitch - Max Trailer Wt. (lbs): - TBD -
• Dead Weight Hitch - Max Tongue Wt. (lbs): - TBD -
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 6000
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 5500
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 900
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 825
• Suspension
• Suspension Type - Front: Torsion Bar
• Suspension Type - Rear: 2-Stage Multi-Leaf
• Spring Capacity - Front (lbs): 2850
• Spring Capacity - Rear (lbs): 2900
• Axle Type - Front: Independent
• Axle Type - Rear: Semi-Floating
• Axle Capacity - Front (lbs): 2850
• Axle Capacity - Rear (lbs): 2900
• Axle Ratio (:1) - Front: 4.10
• Axle Ratio (:1) - Front: 3.73
• Axle Ratio (:1) - Rear: 4.10
• Axle Ratio (:1) - Rear: 3.73
• Shock Absorber Diameter - Front (mm): 30
• Shock Absorber Diameter - Rear (mm): 30
• Stabilizer Bar Diameter - Front (in): 1.10
• Brakes
• Brake Type: Pwr
• Brake ABS System: 4-Wheel
• Disc - Front (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 11.2 x 1.6
• Drum - Rear (Yes or ): Yes
• Rear Drum Diam x Width (in): 11.6 x 2.5
• Tires
• Front Tire Order Code: QJP
• Front Tire Order Code: QNF
• Rear Tire Order Code: QJP
• Rear Tire Order Code: QNF
• Spare Tire Order Code: ZNF
• Spare Tire Order Code: ZCY
• Front Tire Size: P265/70R17
• Front Tire Size: P235/75R16
• Rear Tire Size: P265/70R17
• Rear Tire Size: P235/75R16
• Spare Tire Size: P235/75R16
• Spare Tire Size: Compact
• Front Tire Capacity (lbs): 2074
• Front Tire Capacity (lbs): 1763
• Rear Tire Capacity (lbs): 2074
• Rear Tire Capacity (lbs): 1763
• Spare Tire Capacity (lbs): 2074
• Spare Tire Capacity (lbs): 1763
• Wheels
• Front Wheel Size (in): 17 x 7
• Front Wheel Size (in): 16 x 6
• Rear Wheel Size (in): 17 x 7
• Rear Wheel Size (in): 16 x 6
• Spare Wheel Size (in): 16
• Spare Wheel Size (in): Compact
• Front Wheel Material: Aluminum
• Rear Wheel Material: Aluminum
• Spare Wheel Material: Steel
• Steering
• Steering Type: Pwr
• Steering Ratio (:1), On Center: 18.3
• Steering Ratio (:1), At Lock: 3.20
• Turning Diameter - Curb to Curb (ft): 44.3
• Frame
• Frame Type: Ladder
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 19
• Fuel Tank Location: - TBD -
• Exterior Dimensions
• Wheelbase (in): 126.0
• Length, Overall w/o rear bumper (in): 207.1
• Width, Max w/o mirrors (in): 68.6
• Height, Overall (in): 67.9
• Overhang, Front (in): 33.9
• Overhang, Rear w/o bumper (in): - TBD -
• Front Bumper to Back of Cab (in): 137.3
• Cab to Axle (in): 22.6
• Cab to End of Frame (in): - TBD -
• Ground to Top of Load Floor (in): 31.9
• Ground to Top of Load Floor (in): 30.1
• Ground to Top of Frame (in): - TBD -
• Frame Width, Rear (in): - TBD -
• Ground Clearance, Front (in): - TBD -
• Ground Clearance, Rear (in): - TBD -
• Cargo Area Dimensions
• Cargo Box Length @ Floor (in): 61.1
• Cargo Box Width @ Floor (in): 57.2
• Cargo Box Width @ Wheelhousings (in): 42.6
• Cargo Box (Area) Height (in): 18.6
• Tailgate Width (in): 52.4
• Cargo Volume (ft³): 37.0
• Interior Dimensions
• Passenger Capacity: 6
• Front Head Room (in): 39.6
• Front Leg Room (in): 42.2
• Front Shoulder Room (in): 57.1
• Front Hip Room (in): 53.3
• Second Head Room (in): 38.3
• Second Leg Room (in): 34.8
• Second Shoulder Room (in): 57.1
• Second Hip Room (in): 52.9
• Summary
• Vehicle Name: GMC Canyon
• Body Style: Crew Cab
• Body Code: E63
• Emissions
• EPA Greenhouse Gas Score: 5
